Product features:
High corrosion-resistant:
● Corrosion-resistant vacuum pump consist of imported specific PTFE materials and pump head design, is able to resist the vast majority of corrosive gas, including the transmission mechanism and circuit parts.
Non-pollution & maintenance-free:
● The solvent can be fully recycled by membrane vacuum pump, eliminate the harmful effect that bring to human beings. Without oil and water, keep the laboratory clean and silent. 100% maintenance-free.
Low noise & vibration:
● Corrosion-resistant vacuum pump uses direct drive motor transmission, can keep the noise beneath 70dB with the low noise feature.
Over heating protection:
● Temperature protection switch inside, automatically stop heating when the temperature over-heated, ensure the stability and security of the product.
Technical parameters:
| Model | SM-B20-24-TK |
| Power supply | 220V/50Hz |
| Input power | 120W |
| Pump head type | double-stage pump |
| Maximum vacuum degree | 8~15mbar(no-load) |
| Maximum operation pressure | 1bar |
| Maximum flow | 20L/min |
| Connector specification | 10mm |
| Environment temperature | 5℃～ 40℃ |
| Environment relative humidity | ＜ 80% |
| Pump material | PTFE |
| Combined membrane material | HNBR+PTFE(customized is accpeted) |
| Valve plate material | FKM、FFPM(customized is accpeted) |
| Working system | continuous working |
| Noise | ＜ 70db |
| Rated speed | 1450 RPM |
| Outside dimension （W×D×H）（mm） |
165×315×210 |
| Weight(KG) | 9.6kg |
