Máy kiểm tra màn hình trạm LCD 9106TS / Auto Touch Panel (Load-distance-linearity)Tester 9106TS

Application of all kinds touch panel of cell phones and PDA 『Load-distance-linearity』 multi-function testing. Machine can work with XY axes in random testing place & get changed of testing panel linearity , even check all electronic circuit before testing.

Window Chinese & English version with data storage function for easy operation. (test conditions, load curve, test result and test report, etc.) and output by Excel editing.

Option

●　Touch panel ON point impedance device ●　Active impedance testing system 101 R

Testing Item

●　Touch panel XY direction linearity measure ●　Touch panel ON point force & stroke testing ●　Touch panel planeness testing (vacuole testing) ●　Push-key load cure testing (multipoint stroke) ●　LCD compression testing (multipoint stroke) ●　Three points bending strength testing ●　Normal multipoint force testing (multipoint stroke)

Feature

●　Input X ,Y coordinate randomly, and tester will move automatically. ●　Max. stroke and loading value input for testing automatically. ●　Machine will pause or return while loading value reaches setting. ●　Machine will pause or return while stroke value reaches setting. ●　Test and output the diagrams of each stroke (0.01mm) and loading. ●　Cross-shape cursor can trace the track of each test diagram , so as to determine the Corresponding values of load and displacement. Minimum resolution is 0.01mm . ●　Direct printout and storage (Load-displacement curve, life curve and test report) ●　Data storage in hard disk . (without limit ) ●　The test conditions are programmed by computer pictures . (including test load, stroke , speed,frequency, and pause time….etc.) ●　The title of the test report can be revised at any time .(either in Chinese or in English ) ●　The test report can be transferred to Excel file for editing or output through Network.

Model	9106TS
Load capacity	2kgf
Load Resolution	0.1gf
Load Accuracy	± 0.2% FS
Z axis stroke	200mm(Accuracy±0.03)
Z resolution	0.01mm,0.001mm(Option)
Z speed range	1-200mm/min
X axis stroke	100mm(Accuracy±0.03)
X resolution	0.01mm
Y axis stroke	60mm(Accuracy±0.03)
Y resolution	0.01mm
X-Y stroke	20mm/sec
Max. square measure	100X60mm
Impedance	0.1mΩ-3000Ω(four-wire)
Impedance resolution	0.1mΩ
Impedance accuracy	1mΩ以下(four-wire)
Pressure limited	20kg
Holding table size	120X120mm
Power	AC 110V or 220V
Dimension	300 (W)×520 (D)×640 (H)
Controller dimension	440 (W)×350 (D)×235 (H)
