Cometech QC-41110 Máy kiểm tra mô-men xoắn tự động
Product Serial : QC-41110
Automatic Torque Tester
The load cell is on machine top and the sample will be fixed at the fixture. The lower grips will rotate to test the torque force. User can see the test date directly on the display. Based on different sample test rotation speed required, user can set the speed directly to operate the torque test and analysis. During the test, it shows real-time data of torsion graph and direction and record the sample torsion completely in the spin. According to different test sample, the clamping grips will be customized.
Industry:Eletrical part, Motor, Bearing, Related transmission parts, Package
| Model | QC-41110 |
|---|---|
| Capacity | 0~10N-M |
| Test Speed | 5~50 r/min |
| Test Range | Max. Width 340mm Max. Height 335mm |
| Unit | MN-m, kN-m, N-m, N-cm, mN-m, kgf-m, kgf-cm, kgf-mm, gf-cm, gf-mm, lbf-ft, lbf-in, ozf-in |
| Operation | Use software to for operation and analysis |
| Feature | 1. Real-time graph shows during the test. 2. User friendly test setting module. User can set up direction, speed, test end condition, etc. 3. Available to record the date during the test through USB. |
| Accessory | (Optional) Software Specified grips for sample (additional charge fee based on your sample size) |
| Voltage | AC200~240V |
| Size | 75 cm X 37 cm X 100 cm |
| Weight | 70 kg |
