RONDCOM TOUCH
Guaranteed accuracy temperature range between 15 to 30 ℃
New Entry Model Standard Pursuing Low Price and Ease of Use
Features
Able to select data processing device
3 types of data processing devices (Desktop PC, Laptop PC and Tablet PC) are available. You may select which device to use depending on the usage or installation space.
Class smallest design that uses the world first column moving type structure (patented)
It uses an original column-moving structure and arrangement of the X-axis behind the base has realized a compact design, making it the smallest-in-class.
●Width: 320 mm (49% less than conventional model)
●Height: 500 mm (22% less than conventional model)
●Footprint: 50% less than conventional model
Also, since the Z-axis column can be moved to the left and right, it is possible to access the workpiece both from the right and from the left.
All Necessary Icons on One Screen
ACCTee, roundness measurement and analysis software highly reputed for its operability, was modified to be used exclusively for RONDCOM TOUCH. The operation was made smoother by integrating the icons necessary for measurement and analysis into a single screen.
Newly Developed ACCTee for TABLET
Intuitive operations, such as swiping and pinching, enhance smoothness in measuring operations.
Available in Multiple Languages (Standard Function)
Available languages:
Japanese, English, German, French, Italian, Spanish, Chinese, Korean, Czech, Polish and Portuguese
Alignment Assist Function (Standard Function) (Patented)
