Features

• Wire can be pulled through by hand or using production machinery
• Marks identification codes in many print intervals starting at 6″ or 150mm
• High speed throughput – 600 feet or 200 meters per minute with optional Tape Management System
• Single wire guide handles a range of wire diameters reducing setup time
• Optional tape management system allows for even higher speeds and longer tape lengths
• Simple control and operation
• Coding head allows for quick selection of identification codes
• Digital temperature control with feedback loop
• Optional second tape spool reduces production interruptions
• Rugged, heavy duty construction for the production environment

Specifications

• Wire Size:
  0.040″ to 0.300″ OD (1 mm to 8 mm OD)
• Maximum Speed:
  6,000 feet per hour (1,800 meters per hour)
• Print Drum Drive:
  Direct Drive
• Print Interval:
  every 4″ – 12″ (Every 100 mm – 300 mm)
• Type Form:
  Engraved steel, hardened
• Character Height:
  0.030″ to 0.093″ (1mm to 2.5mm)
• Identification Code Length:
  7 digits with encoder, 20 digits with dedicated print segment
• Print Colors:
  • White
  • Black
  • Yellow
  • Red
  • Blue
  • Others on request
• Spool Lengths:
  • 3/8″ x 3,280 feet or 1/4″ x 3,280 feet
  • 10mm x 1,000m or 6mm x 1,000m
  • Longer lengths available on request

• Tape Capacity:
  1 spool, second spool can be added
• Print Temperature:
  Closed loop P.I.D. controller
• Sequential Marking:
  Optional, 6 digit
• Power Requirements:
  110 VAC 16A, single phase, 50/60 Hz
• Compressed Air:
  80-100 PSI, dry
• Jacket Materials:
  Most common jacket materials including:
  • Nylon
  • Teflon
  • PVC
  • HDPE
  • XLPE
• Spent tape takeup:
  Vacuum
• Machine weight:
  70 lbs. (32 kg)
• Machine Dimensions
  • 26″ x 16″ x 17″ (L x W x H)
  • 660 mm x 410 mm x 430 mm (L x W x H)
  • Mounting:
    Tabletop
