Features

• Accurate sequential marking in meters or feet
• Cost efficient legend segment mounting system
• Push Button, on the fly counter reset
• PLC control system reduces and simplifies maintenance requirements
• Spring-loaded guide rollers allow trouble free passage of cable bulges
• Casters provide easy movement in and out of the line
• Rugged, heavy duty construction for the production environment

Specifications

• Cable size:
  0.2″ to 5″ diameter – 5.0 mm to 125 mm diameter, Larger sizes available on request
• Maximum Speed:
  up to 1,000 feet per minute or up to 300 meters per minute
• Drum Drive:
  Direct Friction Drive or optional servo drive
• Print Interval Accuracy:
  0.9% or optional 0.05%
• Type form:
  Engraved steel, hardened
• Legend Height:
  0.0625″ to 0.5000″ – 1.6 mm to 12.0 mm
• Print Legend Length:
  7 characters per inch – 24 characters per 100mm
• Print Temperature:
  Closed Loop P.I.D. Controller (optional)
• Sequential Marking:
  4 digit to 6 digit
• Sequential Character Height:
  1.6mm to 6mm
• Counter Reset:
  On the fly, electronic pushbutton

• Machine Layout:
  Left to right or right to left
• Print Interval:
  1 Meter or 2 Feet
• Install Location:
  Directly after the extruding head, for printing on hot cable
• Power Requirements:
  208 – 240 VAC 16A, single phase, 50/60 Hz
• Compressed Air:
  80-100 PSI, dry
• Jacket Materials:
  Most common jacket materials including: Nylon, Teflon, PVC, HDPE, XLPE
• Emergency Stop:
  Standard
• Machine Weight:
  400 lbs. – 180 kg
• Machine Dimensions:
  • 40″ X 30″ X 60″ (L X W X H)
  • 1020mm X 765mm X 1525mm (L X W X H)
• Mounting:
  Caster base with leveling screws
