Features

• High accuracy sequential marking in meters or feet
• Reset to zero on the fly
• Length adjustments in increments of ± .001
• Dual tape spools and accumulators eliminate tape splicing
• Microcomputer controlled adjustments reduce the need for operator intervention
• Adjustable guide rollers prevent damage to cables
• Casters for easy movement in and out of the line
• Rugged, heavy duty construction for the production environment
• Optional automatic tape spool changer to avoid down time

Specifications

• Cable Size:
  0.2″ to 5″ dia. (5.0 mm to 127 mm)
• Maximum speed:
  • up to 600 ft/min. (footage mode)
  • up to 200 m/min. (metric mode)
• Drum Drive:
  Micro controlled brushless servo
• Print Interval Accuracy:
  1 : 1,000
• Correction Adjust Increments:
  1 part in 1,000 ±
• Type Form:
  Engraved steel, hardened
• Character Height:
  1/16″ to 5/16″ (1.6 mm to 8.0 mm)
• Print Legend Length:
  240 characters metric or 120 characters footage at 7 characters per inch
• Print Colours:
  White, black, yellow (others on request)
• Spool Length:
  • 3/8″ x 42,000 feet
  • 1/4″ x 72,000 feet
  • 10 mm x 12,805 m
  • 6 mm x 21,951 m
• Spool Capacity:
  2
• Print Temperature
  Micro controlled (P.I.D.)
• Sequential Marking:
  6 digit

• On The Fly Reset:
  Yes
• Machine Layout:
  Left to Right or Right to Left
• Print Interval:
  Metric or Footage
• Power Requirements:
  280-240 V, 16A, single phase, 50/60 Hz
• Compressed Air:
  100 psi @ 5 to 10 CFM, dry
• Jacket Materials:
  Rubber, Nylon, PVC, Med & HDPE, various cross-linked and semi-conductive materials
• Spent Tape Takeup:
  Vacuum
• Fault & Warning Signals:
  8 digit status display and warning light
• Stopped Line Response:
  Automatic lift carriage drop
• Emergency Stop:
  Standard
• Machine Weight:
  545 kg (1,200 lbs.)
• Mounting:
  Caster base with levelling screws
