Features

• High accuracy sequential marking in meters
• Length adjustments in increments of ± .001
• Dual tape spools and accumulators eliminate tape splicing
• Microcomputer controlled adjustments reduce the need for operator intervention
• Adjustable guide rollers prevent damage to cables
• Casters for easy movement in and out of the line
• Rugged, heavy duty construction for the production environment
• Optional automatic tape spool changer to avoid down time

  Specifications

  Bạn cần hỗ trợ về s.phẩm?

  Call 024-6687-2330

  gb@pemax-mte.com

  • Cable Size:
    5.0 mm to 127 mm
  • Maximum speed:
    up to 200 m/min
  • Drum Drive:
    Micro controlled brushless servo
  • Print Interval Accuracy:
    1 : 1,000
  • Correction Adjust Increments:
    1 part in 1,000 ±
  • Type Form:
    Engraved steel, hardened
  • Character Height:
    1.6 mm to 8 mm
  • Print Legend Length:
    240 characters metric at 7 characters per 25 mm
  • Print Colours:
    White, black, yellow (others on request)
  • Spool Length:
    10 mm x 12,805 m or 6 mm x 21,951 m
  • Spool Capacity:
    2
  • Print Temperature
    Micro controlled (P.I.D.)
  • Sequential Marking:
    6 digit

  Bạn cần hỗ trợ về s.phẩm?

  Call 024-6687-2330

  gb@pemax-mte.com

  • On The Fly Reset:
    Yes
  • Machine Layout:
    Left to Right or Right to Left
  • Print Interval:
    Metric
  • Power Requirements:
    280-240 V, Single phase, 16A, 50/60 Hz
  • Compressed Air:
    80 psi @ 5 to 10 CFM, dry
  • Jacket Materials:
    Rubber, Nylon, PVC, Med & HDPE, various cross-linked and semi-conductive materials
  • Spent Tape Takeup:
    Vacuum
  • Fault & Warning Signals:
    8 digit status display and warning light
  • Stopped Line Response:
    Automatic lift carriage drop
  • Emergency Stop:
    Standard
  • Machine Weight:
    450 kg
  • Mounting:
    Caster base with leveling screws
