Features

• Embossed printing
• Both double and single sided printing
• Accurate length measurement
• Easy calibration through a keyboard
• Rapid changeover of print legend to minimize production interruptions
• Automatic reset to zero with outputs to cutter or operator signal
• Optional coding head for rapid changeover of product code or run identification
• Rugged durable construction for the production environment
• Heavy duty casters and jack screws for easy movement in and out of the production line

Specifications

• Print Interval:
  2 feet or 1 meter
• Cable Size:
  10 to 102 mm diameter (.4″ to 4″)
• Line Speed:
  3 to 100 meters / minute
• Sequential Marking Accuracy:
  .1%
• Print Inserts:
  • Engraved Steel
  • Gravure Surface
• Character Height:
  1.6 mm to 5 mm
• Sequential Marking:
  6 digits
• Product Coding Head:
  Optional up to 21 wheels with 11 characters each
• Machine Layout:
  • Left to Right
  • Right to Left

• Machine Dimensions:
  • Length 1.0 m, Width 63.5 cm, Height 132.1 cm
  • Length 40″, Width 25″, Height 52″
• Weight:
  270 kg (600 lbs.)
• Mounting:
  Caster base with leveling screws
• Power Requirements:
  115/220 VAC, 200 watts
• Compressed Air:
  80 psi
• Jacket Materials:
  PVC, Polyethylene, XLPE,Neoprene, etc.
• Remote Status Indicator:
  Available
• Remote Emergency Stop:
  Available
